I'd be glad to provide information about the AutoCAD circle, rectangle, and polygon commands:
Circle Command:
Purpose: Creates a circular shape.
Usage:
   * Type CIRCLE or C in the command line.
   * Specify the center point of the circle by clicking or entering coordinates.
   * Choose a method to define the radius:
     * Radius: Enter the desired radius value.
     * Diameter: Enter the diameter value.
     * Point: Click a second point on the circle's circumference.
Options:
   * Center: Specifies the center point of the circle.
   * Radius: Sets the radius of the circle.
   * Diameter: Sets the diameter of the circle.
   * Point: Defines the circle's circumference by clicking a second point.
   * Tangents: Draws a circle tangent to two specified objects.
Rectangle Command:
Purpose: Creates a rectangular shape.
Usage:
   * Type RECTANGLE or REC in the command line.
   * Specify the first corner point of the rectangle by clicking or entering coordinates.
   * Choose a method to define the second corner point:
     * Second corner: Click a second corner point.
     * Other corner: Enter the coordinates of the opposite corner.
     * Width/Height: Enter the width and height values.
Options:
   * First corner: Specifies the first corner point of the rectangle.
   * Second corner: Specifies the second corner point of the rectangle.
   * Other corner: Specifies the opposite corner of the rectangle.
   * Width/Height: Sets the width and height of the rectangle.
Polygon Command:
Purpose: Creates a regular polygon shape.
Usage:
   * Type POLYGON or POL in the command line.
   * Specify the center point of the polygon by clicking or entering coordinates.
   * Enter the number of sides for the polygon.
   * Choose a method to define the size of the polygon:
     * Inscribed: The polygon is inscribed within a circle.
     * Circumscribed: The polygon circumscribes a circle.
     * Edge: Enter the length of one edge of the polygon.
Options:
   * Center: Specifies the center point of the polygon.
   * Sides: Sets the number of sides of the polygon.
   * Inscribed: Inscribes the polygon within a circle.
   * Circumscribed: Circumscribes the polygon around a circle.
   * Edge: Sets the length of one edge of the polygon.
I hope this information is helpful!
