Raspberry Pi USB Camera Setup (Python + OpenCV Beginner Tutorial)
In this tutorial, we’ll connect a USB camera to a Raspberry Pi and use Python with OpenCV and Matplotlib to display a live video stream. This is a great beginner-friendly project and a solid foundation for computer vision applications like object detection, robotics, and AI projects.
🔧 What you’ll learn:
How to access a USB camera on Raspberry Pi
Capturing live video frames using OpenCV
Converting image formats (BGR → RGB)
Displaying a live video feed using Matplotlib
Creating a simple real-time loop for image updates
How to increase the display size for a better viewing experience
💡 This setup works great for future projects like motion detection, AI-powered wildlife monitoring, or robotics vision systems.
🧠 Python Code (Standard Version):
import cv2
from matplotlib import pyplot as plt
cap = cv2.VideoCapture(0)
plt.ion() # Turn on interactive mode
fig, ax = plt.subplots()
im = None
while True:
ret, frame = cap.read()
if not ret:
print("Failed to grab frame")
break
frame_rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
if im is None:
im = ax.imshow(frame_rgb)
ax.axis('off')
else:
im.set_data(frame_rgb)
plt.pause(0.01) # Small pause to update the figure
Optional: stop loop on keyboard interrupt
try:
plt.gcf().canvas.flush_events()
except KeyboardInterrupt:
break
cap.release()
plt.close()
🖥️ Python Code (Larger Display Version):
import cv2
from matplotlib import pyplot as plt
cap = cv2.VideoCapture(0)
plt.ion() # Turn on interactive mode
fig, ax = plt.subplots(figsize=(10, 6)) # more balanced size
plt.subplots_adjust(left=0, right=1, top=1, bottom=0)
ax.axis('off')
im = None
while True:
ret, frame = cap.read()
if not ret:
print("Failed to grab frame")
break
frame_rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
if im is None:
im = ax.imshow(frame_rgb, aspect='auto')
else:
im.set_data(frame_rgb)
plt.pause(0.01)
try:
plt.gcf().canvas.flush_events()
except KeyboardInterrupt:
break
cap.release()
plt.close()
🚀 Next Steps:
Add object detection (YOLO, TensorFlow Lite, etc.)
Record video or save snapshots
Integrate with a robot or smart system
🌐 Project Page:
https://craftyrobotics.com/
