How to solve sharp error code E7-10 is explained. Contents Sharp AR ||
2048 AR-2348 AR-237 AR-238 AR-6020 6023 6026 6030 MX-237 MX-238
Scanner returns trouble
Mirror unit abnormality
Scanner wire disconnection
Origin detection sensor abnormality
Mirror motor harness abnormality
Use SIM 1-1 to check the mirror reciprocating operations.
When the mirror does not return.
Check for disconnection of the scanner wire.
Check the harness and the connector between the mirror motor and the MCU PWB.
Replace the mirror unit.
Replace the MCU PWB.
When the mirror does feed.
Use SIM 1-2 to check the mirror home position sensor.
page
Code: CH-Blink
Developing cartridge not installed
Developing unit disconnection
MCU PWB abnormality
The toner cartridge is not installed.
Check installation of the developing unit.
Replace the MCU PWB.
Install toner cartridge.
Code: CH-ON
Side door open
Side door sensor abnormality
MCU PWB abnormality
Check that all the side doors are closed.
Replace the MCU PWB.
Code E7-01
Duplex model memory error/ Image data error
1. The memory capacity on the MCU PWB is wrong.
2. Setting for a single surface model is wrong.
1. Use SIM26-39 to check to confirm that the memory capacity is 64MB. If it is not 64MB, replace the MCU PWB.
2. If SIM26-04 is set to 1, change the setting to 0. If it is 0, replace the MCU PWB.
Code E7-06
Image data decode error
MCU PWB abnormality
USB cable trouble
Replace the MCU PWB.
Replace the USB cable.
Code E7-10
Shading error (Black correction)
Improper connection of the CCD unit flat cable
CCD unit abnormality
MCU PWB abnormality.
Check connection of the CCD unit flat cable.
Check the CCD unit.
Code E7-11
Shading error (White correction)
Causes:
Improper connection of the CCD unit flat cable
Dirt on the mirror, the lens, and the reference white plate
Copy lamp lighting abnormality
CCD unit abnormality
MCU PWB abnormality
(When occurred in the SPF scan position.)
Improper installation of the mirror unit
Clean the mirror, the lens, and the reference white plate.
Check lighting and the light quantity of the copy lamp (SIM05-03).
Check the CCD unit.
Check the MCU PWB.
