Binary code to Gray code conversion with practical explanation
In this video, I've explained how to convert a given Binary number to Gray code, and also I've explained how to design a circuit to convert this on the breadboard using XOR IC 7486.
Components:
SN74ls86 (https://amzn.to/3trgvqJ)
6 pin switch (https://amzn.to/3tuKE8r)
Working of pull down resistor:
• Pull up and pull down resistor
Self locking push button switch (DPDT switch):
• How to use 6 pins 8x8 mm self locking DPDT...
Gray code to Binary code:
• Gray code to Binary code conversion with p...
XOR ic 7486 tutorial, Video link:
• SN74LS86 | XOR logic gate IC 7486 explaine...
